SUMIKO
PHONO CARTRIDGES |
 |

1/2"
Mount Moving
Coil & High Output Moving Coil Audiophile
Cartridges |
CELEBRATION
II
PEARWOOD SIGNATURETM
Moving Coil
- Stylus Type:
Ultra-Low Mass Ogura Jewel Co. P9 Stylus.
- Suspension:
Synthetic Rubber.
- Cantilever
Material: Long Grain Boron.
- Frequency Response:
10 Hz. - 40 kHz. +/- 1.5 dB.
- Output
Voltage: 0.5 mV per channel at 1 kHz.; 3.5 cm./sec. peak
recorded velocity. Output from each channel within 2 dB.
- Internal
Impedance: 30 Ohms.
- Channel
Separation: 30 dB at 1 kHz.
- Channel
Balance: 0.5 dB.
- Dynamic Compliance:
12 x 10-6 cm/dyne.
- Load Impedance
Range: 100 ohms - 1,000 ohms.
- Capacitance
Range: 100 - 300 pF.
- Tracking Force
Range: 1.9 to 2.2 grams.
- Recommended Tracking Force:
2.0 grams.
- Net Mass:
7.0 grams.
- Mounting:
Standard 1/2"
(12.7mm) Mounting Centers.
- No User Replaceable Stylus.
Requires a diamond Re-Tip or Trade In / Trade Up. Please contact
a Sales Consultant at 1-954-938-9889 for further information.
"Hand fitted with a silky pearwood body that recalls the glamorous low-output moving coil cartridges of analog's past; Celebration commemorates our 25 years designing and distributing the finest in phono cartridges. Using a blend of cutting edge materials and the tried and true, Celebration returns the excitement of analog's glory days. The mechanical foundation for the intricate workings is a unique machined alloy "cradle" into which the entire generating system of the cartridge is fitted, held in place with a single compression screw. Within this structure, the magnet is mounted against a yoke that creates a linear, uniform density magnetic field completely surrounding the coil. To make the most effective use of this ingenious structure, complementary components were carefully selected: a classic Alnico magnet for a robust 0.5 mV output; a low mass PH stylus for ease of set-up; a long-grain boron cantilever for stiffness and self quieting; new synthetic rubber elastomers in the suspension system for superior performance and longevity. The sound of Celebration is the product not only of Sumiko's many years experience fine tuning fine sound, but of our continuing desire to reveal the vibrant and exciting colors of analog. experience fine tuning the sound."
|


|
|
Your Price
$2,000.00 Each
EACH
Free Shipping, Handling and Insurance on this phono
cartridge for immediate delivery within the Continental United States.
|
BLACKBIRDTM
High Output Moving
Coil
- Stylus Type:
0.3 x 0.7
mil. Elliptical Configuration.
- Frequency Response:
12 Hz. - 50 kHz.
- Output
Voltage: 2.5 mV per channel at 1 kHz.; 5 cm./sec. peak
recorded velocity. Output from each channel within 2 dB.
- Channel
Separation: Minimum 35 dB at 1 kHz.
- Channel
Balance: Within 0.5 dB.
- Compliance:
11 x 10-6 cm/dyne.
- Optimum Load: 47, 000 ohms
resistance in parallel with 250 to picofarads total capacitance.
- Tracking Force
Range: 1.7 to 2.1 grams.
- Recommended Tracking Force:
2.0 grams.
- Net Weight:
8.l grams.
- Mounting:
Standard 1/2"
(12.7mm) Mounting Centers.
- No User Replaceable Stylus.
Requires a diamond Re-Tip or Trade In / Trade Up. Please contact
a Sales Consultant at 1-954-938-9889 for further information.
"Designed for exceedingly low noise levels, wide dynamic range and the highest possilbe fidelity in its price class, Blackbird is destined to become an analog classic. Each cartridge is assembled using time honored, labor intensive techniques, hand calibrated and critically auditioned to meet the most rigorous standards of consistancy. The main advantage of high output moving coil cartridges is the elimination of any additional gain stages, resulting in an overall reduction of the noise floor. With 2.5mV directly driving a standard 47k Ohm RIAA phono stage, the best possible signal to noise ratio is realized. Nothing but music emerges from your most treasured recordings."
|

|
|
Your Price
$ 899.00 Each
EACH
Free Shipping, Handling and Insurance on this phono
cartridge for immediate delivery within the Continental United States.
|
|

1/2"
Mount High Output Moving Coil
Audiophile Cartridges
|
BLUE
POINT SPECIAL EVO IIITM
High Output Moving Coil
- Stylus Type:
0.3 x 0.7
mil. Elliptical Configuration.
- Frequency Response:
12 Hz. - 50 kHz.
- Output
Voltage: 2.5 mV per channel at 1 kHz.; 5 cm./sec. peak
recorded velocity. Output from each channel within 2 dB.
- Channel
Separation: Minimum 35 dB at 1 kHz.
- Channel
Balance: Within 0.5 dB.
- Compliance:
11 x 10-6 cm/dyne.
- Optimum Load: 47, 000 ohms
resistance in parallel with 250 to picofarads total capacitance.
- Tracking Force
Range: 1.7 to 2.1 grams.
- Recommended Tracking Force:
2.0 grams.
- Net Weight:
8.l grams.
- Mounting:
Standard 1/2"
(12.7mm) Mounting Centers.
- No User Replaceable Stylus.
Requires a diamond Re-Tip or Trade In / Trade Up. Please contact
a Sales Consultant at 1-954-938-9889 for further information.
"Sumiko's Blue Point Special is a high output moving coil phono cartridge with an open generator design and alloy cantilever. The output is 2.5 mV. Low mechanical impedance mounting system ingeniously dissipates resonance."
|

|
|
Your Price
$ 399.00 Each
EACH
Free Shipping, Handling and Insurance on this phono
cartridge for immediate delivery within the Continental United States.
|
BLUE
POINT No. 2TM
High Output Moving Coil
- Stylus Type:
0.3 x 0.7
mil. Elliptical Configuration.
- Frequency Response:
15 Hz. - 35 kHz.
- Output
Voltage: 2.5 mV per channel at 1 kHz.; 5 cm./sec. peak
recorded velocity. Output from each channel within 2 dB.
- Channel
Separation: Minimum 32 dB at 1 kHz.
- Channel
Balance: Within 0.5 dB.
- Compliance:
15 x 10-6 cm/dyne.
- Optimum Load: 47, 000 ohms
resistance in parallel with 250 to picofarads total capacitance.
- Tracking Force
Range: 1.5 to 1.8 grams.
- Recommended Tracking Force:
1.7 grams.
- Net Weight:
5.l grams.
- Mounting:
Standard 1/2"
(12.7mm) Mounting Centers.
- No User Replaceable Stylus.
Requires a diamond Re-Tip or Trade In / Trade Up. Please contact
a Sales Consultant at 1-954-938-9889 for further information.
"The Sumiko Blue Point high output moving coil phono cartridge has an output of 2.5 mV, an alloy cantilever, and Blue Point-cut Elliptical diamond stylus."
|

|
|
Your Price
$ 299.00 Each
EACH
Free Shipping, Handling and Insurance on this phono
cartridge for immediate delivery within the Continental United States.
|

1/2"
Mount Moving Magnet Audiophile Cartridges
|
PEARL
Moving Magnet
- Stylus Type:
0.2 x 0.8
mil. Elliptical Configuration.
- Frequency Response:
12 Hz. - 30 kHz.
- Output
Voltage: 5.0 mV per channel at 1 kHz.; 5 cm./sec. peak
recorded velocity. Output from each channel within 2 dB.
- Channel
Separation: Minimum 30 dB at 1 kHz.
- Channel
Balance: Within 0.5 dB.
- Compliance:
15 x 10-6 cm/dyne.
- Optimum Load: 47, 000 ohms
resistance in parallel with 250 to picofarads total capacitance.
- Tracking Force
Range: 1.5 to 2.0 grams.
- Recommended Tracking Force:
2.0 grams.
- Net Weight:
6.0 grams.
- Mounting:
Standard 1/2"
(12.7mm) Mounting Centers.
- User Replaceable Stylus RS-PEA
"Moving magnet phono cartridge with alloy cantilever, bonded elliptical stylus and 4.0mV output."
|

|
|
Your Price
$ 95.00 Each
EACH
Free Shipping, Handling and Insurance on this phono
cartridge for immediate delivery within the Continental United States.
|
BLACK
PEARL
Moving Magnet
- Stylus Type:
0.5
mil. Spherical Configuration.
- Frequency Response:
18 Hz. - 27 kHz.
- Output
Voltage: 5.0 mV per channel at 1 kHz.; 5 cm./sec. peak
recorded velocity. Output from each channel within 2 dB.
- Channel
Separation: Minimum 28 dB at 1 kHz.
- Channel
Balance: Within 0.5 dB.
- Compliance:
15 x 10-6 cm/dyne.
- Optimum Load: 47, 000 ohms
resistance in parallel with 250 to picofarads total capacitance.
- Tracking Force
Range: 1.5 to 2.0 grams.
- Recommended Tracking Force:
2.0 grams.
- Net Weight:
6.0 grams.
- Mounting:
Standard 1/2"
(12.7mm) Mounting Centers.
- User Replaceable Stylus RS-BLP
"The Black Pearl is a moving magnet phono cartridge with alloy cantilever and bonded spherical stylus, 4.0 mV output."
|

|
|
Your Price
$ 75.00 Each
EACH
Free Shipping, Handling and Insurance on this phono
cartridge for immediate delivery within the Continental United States.
|
OYSTER
Moving Magnet
- Stylus Type:
0.6 mil. Spherical Configuration.
- Frequency Response:
30 Hz. - 20 kHz.
- Output
Voltage: 4.0 mV per channel at 1 kHz.; 5 cm./sec. peak
recorded velocity. Output from each channel within 2 dB.
- Channel
Separation: Minimum 25 dB at 1 kHz.
- Channel
Balance: Within 1.0 dB.
- Compliance:
12 x 10-6 cm/dyne.
- Optimum Load: 47, 000 ohms
resistance in parallel with 250 to picofarads total capacitance.
- Tracking Force
Range: 1.25 to 2.5 grams.
- Recommended Tracking Force:
2.3 grams.
- Net Weight:
5.3 grams.
- Mounting:
Standard 1/2"
(12.7mm) Mounting Centers.
- User Replaceable Stylus RS-OYS
"Moving magnet phono cartridge with alloy cantilever. Bonded spherical stylus, 4.0 mV output."
|

|
|
Your Price
$ 55.00 Each
EACH
Free Shipping, Handling and Insurance on this phono
cartridge for immediate delivery within the Continental United States.
|
