PICKERING
&
COMPANY
a Stanton Magnetics
Company
PHONO
CARTRIDGES |
 |
| 1/2"
Mount System |
XV15/400E
- Stylus Type: 0.4
mil. x 0.7 mil. Elliptical Diamond Stylus Configuration.
- Frequency Response:
10 Hz. - 25 kHz.
- Output
Voltage: 5.5 mV per channel at 1 kHz.; 5 cm./sec. peak
recorded velocity. Output from each channel within 2 dB.
- Channel
Separation: Minimum 35dB at 1 kHz.
- Tracking Force
Range: 1.0 to 2.0 grams.
- Mounting:
Standard 1/2" (12.7mm) Mounting Centers.
|
|
|
YOUR PRICE
$132.87
EACH
This
Product is
UNAVAILABLE
at this time.
SORRY!
|
V15/AME
3
- Stylus Type: 0.4
mil. x 0.7 mil. Elliptical Diamond Stylus Configuration
with an Aluminum Cantilever.
- Frequency Response:
10 Hz. - 23 kHz.
- Output
Voltage: 3.5 mV per channel at 1 kHz.; 5 cm./sec. peak
recorded velocity. Output from each channel within 2 dB.
- Channel
Separation: Minimum 25dB at 1 kHz.
- Tracking Force
Range: 1.0 to 2.0 grams.
- DC Resistance:
535 Ohms.
- Inductance:
400 mH.
- Vertical
Compliance: 16 x 10-6 cm/dyne.
- Cartridge
Weight: 5.5 grams.
- Mounting:
Standard 1/2" (12.7mm) Mounting Centers.
|
|
|
YOUR PRICE
$122.31
EACH |
V15/SERIES
II EE
- Stylus Type: 0.4
mil. x 0.7 mil. Elliptical Diamond Stylus Configuration
with an Aluminum Cantilever.
- Frequency Response:
10 Hz. - 20 kHz.
- Output
Voltage: 3.5 mV per channel at 1 kHz.; 5 cm./sec. peak
recorded velocity. Output from each channel within 2 dB.
- Channel
Separation: Minimum 25dB at 1 kHz.
- Tracking Force
Range: 1.0 to 2.0 grams.
- DC Resistance:
535 Ohms.
- Inductance:
400 mH.
- Vertical
Compliance: 16 x 10-6 cm/dyne.
- Cartridge
Weight: 5.5 grams.
- Mounting:
Standard 1/2" (12.7mm) Mounting Centers.
|
|
|
YOUR PRICE
$105.27
EACH |
V15/SERIES
II E
- Stylus Type: 0.4
mil. x 0.7 mil. Elliptical Diamond Stylus Configuration
with an Aluminum Cantilever.
- Frequency Response:
10 Hz. - 18 kHz.
- Output
Voltage: 3.5 mV per channel at 1 kHz.; 5 cm./sec. peak
recorded velocity. Output from each channel within 2 dB.
- Channel
Separation: Minimum 22dB at 1 kHz.
- Tracking Force
Range: 1.0 to 2.0 grams.
- DC Resistance:
535 Ohms.
- Inductance:
400 mH.
- Vertical
Compliance: 14 x 10-6 cm/dyne.
- Cartridge
Weight: 5.5 grams.
- Mounting:
Standard 1/2" (12.7mm) Mounting Centers.
|
|
|
YOUR PRICE
$88.65
EACH |
NP/AC
(PREMIER
SERIES)
- Stylus Type: 0.7
mil. Conical Diamond Stylus Configuration
with an Aluminum Cantilever.
- Frequency Response:
10 Hz. - 18 kHz.
- Output
Voltage: 10.0 mV per channel at 1 kHz.; 5 cm./sec. peak
recorded velocity. Output from each channel within 2 dB.
- Channel
Separation: Minimum 21dB at 1 kHz.
- Tracking Force
Range: 3.0 to 7.0 grams.
- Vertical
Compliance: 14 x 10-6 cm/dyne.
- Mounting:
Standard 1/2" (12.7mm) Mounting Centers.
|
|
|
YOUR PRICE
$65.80
EACH |
|
Convertible
Mount System
Adapts
to Both 1/2" and "P" Mount Systems |
XSP/3003
- Stylus Type:
Stereohedron Configuration
with an Aluminum Cantilever.
- Magnet Type: Samarium
Cobalt.
- Frequency Response:
10 Hz. - 30 kHz.
- Output
Voltage: 0.9 mV per channel at 1 kHz.; 5 cm./sec. peak
recorded velocity. Output from each channel within 2 dB.
- Channel
Separation: Minimum 35dB at 1 kHz.
- Tracking Force
Range: 1.0 to 1.5 grams.
- DC Resistance:
600 Ohms.
- Inductance:
270 mH.
- Cartridge
Weight: 5.9 grams.
- Mounting:
Convertible to
Standard 1/2" (12.7mm) Mounting Centers and "P" Mounting
Configuration.
|
|
|
YOUR PRICE
$205.14
EACH
This
Product is
UNAVAILABLE
at this time.
SORRY!
|
TL-2S
- Stylus Type:
Stereohedron Configuration
with an Aluminum Cantilever.
- Frequency Response:
10 Hz. - 22 kHz.
- Output
Voltage: 4.4 mV per channel at 1 kHz.; 5 cm./sec. peak
recorded velocity. Output from each channel within 2 dB.
- Channel
Separation: Minimum 32dB at 1 kHz.
- Tracking Force
Range: 0.75 to 1.5 grams.
- DC Resistance:
1300 Ohms.
- Inductance:
900 mH.
- Cartridge
Weight: 6.0 grams.
- Mounting:
Convertible to
Standard 1/2"
(12.7mm) Mounting Centers and
"P" Mounting
Configuration.
|
|
|
YOUR PRICE
$194.37
EACH |
TL-2
- Stylus Type: 0.3
mil. x 0.7 mil. Elliptical Diamond Stylus Configuration.
- Frequency Response:
10 Hz. - 22 kHz.
- Output
Voltage: 4.4 mV per channel at 1 kHz.; 5 cm./sec. peak
recorded velocity. Output from each channel within 2 dB.
- Channel
Separation: Minimum 32dB at 1 kHz.
- Tracking Force
Range: 0.75 to 1.5 grams.
- DC Resistance:
1300 Ohms.
- Inductance:
900 mH.
- Cartridge
Weight: 6.0 grams.
- Mounting:
Convertible to
Standard 1/2"
(12.7mm) Mounting Centers and
"P" Mounting
Configuration.
|
|
|
YOUR PRICE
$142.90
EACH |
TLE
TYPE 2
- Stylus Type: 0.4
mil. x 0.7 mil. Elliptical Diamond Stylus Configuration.
- Frequency Response:
10 Hz. - 20 kHz.
- Output
Voltage: 3.0 mV per channel at 1 kHz.; 5 cm./sec. peak
recorded velocity. Output from each channel within 2 dB.
- Channel
Separation: Minimum 28dB at 1 kHz.
- Tracking Force
Range: 0.75 to 1.5 grams.
- DC Resistance:
535 Ohms.
- Inductance:
400 mH.
- Cartridge
Weight: 5.9 grams.
- Mounting:
Convertible to
Standard 1/2"
(12.7mm) Mounting Centers and
"P" Mounting
Configuration.
|
|
|
YOUR PRICE
$126.78
EACH |
TLE
- Stylus Type: 0.4
mil. x 0.7 mil. Elliptical Diamond Stylus Configuration.
- Frequency Response:
10 Hz. - 20 kHz.
- Output
Voltage: 4.4 mV per channel at 1 kHz.; 5 cm./sec. peak
recorded velocity. Output from each channel within 2 dB.
- Channel
Separation: Minimum 28dB at 1 kHz.
- Tracking Force
Range: 0.75 to 1.5 grams.
- DC Resistance:
535 Ohms.
- Inductance:
400 mH.
- Cartridge
Weight: 5.9 grams.
- Mounting:
Convertible to
Standard 1/2"
(12.7mm) Mounting Centers and
"P" Mounting
Configuration.
|
|
|
YOUR PRICE
$90.03
EACH |
|
